Three-dimensional image measuring

Three-dimensional image measuring
Three-dimensional image measuring
Price And Quantity
  • 1
  • Unit/Units
    Product Description

    THE USAGE:

    The instrument is widely used in mechanical,electronic instrumentation,plastics and other industries.

    Parameters

    Model

    VMS-1510T

    VMS-2010T

    VMS-2515T

    VMS-3020T

    VMS-4030T



    WORK TABLE

    Metal table size(mm)

    354*228

    404*228

    450*280

    506*356

    606*466

    Glass table size(mm)

    210*160

    260*160

    306*196

    350*280

    450*350

    Stroke(mm)

    150*100

    200*100

    250*150

    300*200

    400*300

    Weight(kg)

    100

    150

    120

    200

    400

    Out dimension(L*W*H)(mm)

    600*530*950

    600*550*920

    680*670*1020

    679*596*1017

    960*750*1100

    Data measurement system

    200mm Z-axis vertical stroke:200mm(including focusing)

    92mm work distance:92mm

    0.0005mm X,Y display resolution

    X,Y display error:≤(3+L/200)μm

    Function

    Precision side head as IBR probe can be measured lines.angles,circles,center distance,angle,height,flat pitch,spatial distance,flatness,spheres,etc.

    Trade Information
    • Shenzhen
    • 30 Units Per Month
    • 15 Days
    • Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside.
    • CE,ISO
