Two-dimensional image measuring instrument

Thus machine is mainly used to measure the size of products and molds. The secondary metering instrument is mainly used to measure the two-dimensional plane detection of thin products and smaller products or other parts.

Parameter:

Woke table:350*450mm

Class table size:274mm

X axis strike:300mm

Y axis stroke:200mm

Out dimension(L*W*H):480*650*1000mm

Weight:200kg

Z axis vertical stroke:170mm

Work distance:95mm(0.5m)

X. Y display error3+L/200m

Image system:camera:CCD(JAPAN`S SONY chip). magnification zoom lens:0.7`4.5X(Fixed zoom,without each calibration). total magnification video:30X~230X. object field:7`1.1mm
